SIHI CBE/CBM Chemical Process Pumps ANSI ISO-福斯Flowserve
The standard chemical process pumps of the CBE/CBM range are horizontal, single-stage volute casing pumps with dimensions to ISO 2858 and meet the technical requirements of ISO 5199 and ISO 15783
Fully enclosed impellers for high efficiency, low NPSHr applications
Modular configuration of either bare shaft end or close-coupled design
Shaft sealing options are single or double acting mechanical seals or magnetic drives
Hastelloy, ceramic and high efficiency containment shells for demanding magnetic coupled applications
Back pull-out design allows removal of rotating element without removing casing, piping or motor
Ceramic Canister 1:1 exchange with standard and high efficiency Hastelloy shells
Samarium Cobald magnet life extended by temperature limits up to 350°C (662°F) and reversible torque within the allowed temperature range
Continues operation at 10% BEP due to low flow
Process fluid is mechanically sealed from leakage via an optional additional containment shell
Lower total cost of ownership due to high efficiency and low NPSH hydraulics
No maintenance necessary when using the SSiC bearing
Easy alignment and true back pull-out design with closed coupled assembly
